Backplane

There are many different ways to connect backplanes; ept offers the right connectors for the job.


Highly Diverse and Time Proven
The DIN 41612/IEC 60603-2 product series consists of 12 basic types and other supplementary versions with a 2.54-mm or 5.08-mm pitch.The choices range from signal connectors with a current rating of up to 1.5 A to power connectors that can handle up to 5.6 A or even 15 A. The wealth of variants makes it possible to use this family of connectors for a very wide range of applications. Standardization ensures that the connectors are compatible with products from different manufacturers.
The DIN 41612/IEC 60603-2 product series consists of 12 basic types and other supplementary versions with a 2.54-mm or 5.08-mm pitch.The choices range from signal connectors with a current rating of up to 1.5 A to power connectors that can handle up to 5.6 A or even 15 A. The wealth of variants makes it possible to use this family of connectors for a very wide range of applications. Standardization ensures that the connectors are compatible with products from different manufacturers.

For MicroTCA® applications, ept offers power connectors that meet PICMG® specifications.

For ATCA® applications, ept offers both signal connectors and power connectors that meet PICMG® specifications.

The hm 2.0 series of hardmetric connectors was developed in accordance with the international IEC 61076-4-101 standard.

Velox® is a modular connector system for high-speed backplane applications.
